The basic knowledge about Magento® and order management

How Magento® deals with the customer's orders ?

Orders in Magento are arranged as a structured group of data that are shared in different database table instances.

The main instance is the Order table that contains the summary of each order placed (date, total amount, tax, customer,...).

Attached to this instance there are 3 sub-instances concerning the order details:

  • Product
  • Shipping address
  • Billing address

Those instances describe which products have been ordered and gives details about the customer's addresses.

There are 4 other sub-instances that help to store the different steps in the order process:

  • Payments
  • Invoice
  • Shipment
  • Creditmemo

The above instances can be simply summarized:

Of course, there is much more data that you can extract from your Magento database and this is where Orders Export Tool can help.

How Orders Export Tool exports the Magento® Data?

Orders Export Tool enables the export of all the order data into XML or TXT/CSV files.

These files can then be transfered into your CRM/ERP software or can be used for reporting purposes.

The way this extension deals with the order data is very simple. When configuring your export profile, you have to complete a template in which you can use static and dynamic values.

Static and Dynamic values

Static values are data that don't change from one order to another and that are added in the ouput file to make it readable.

Dynamic values are data that are different for each order such as price, address, product ordered...

Imagine you want to export all the orders placed into you Magento webstore and what you want to get is a simple TXT file including the order number and the total amount of each order. What you get should look like:

#123456789 	$150.00
#234567891	$275.00
#345678912	$450.00

Your template would be very simple:

#{increment_id}  ${total_paid}

# and $ are static values while {increment_id} and {total_paid} are dynamic values that changed for each order.

The instances

{increment_id} and {total_paid} refer to the Order instance and could also be written as {increment_id order} and {total_paid order}.

You might need to complete your export file with the method used by your customers to pay their order. This data can be found in the Payment instance and you should use {method payment}. This syntax means you want to know the value of the payment method for each order.

How to use Orders Export Tool in 4 steps?

Orders Export Tool is quite easy to use. You'll need 4 steps to configure your extension. Once these steps completed, your extension will be ready to use.

STEP 1: Configure Orders Export Tool in a general way

To configure your extension, first go to:
SystemConfigurationWyomindOrders Export Tool

There you get two subtabs.

Cron job reporting

Orders Export Tool allows you to enable cron job reporting.

  • Send the reports to
    You have the possibility to send these generation report to email addresses (they must be separated by a comma).
  • Report title
    You can also change the report name
  • Debug mode
    Decide to enable the debug mode or not.

Core setting

Note that the Core Settings part is for advanced users.

  • Orders grid to display
    The default value is "Mage_Adminhtml_Block_Sales_Order_Grid"
  • Profile IDs to execute while placing an order
    You will also have the possibility to execute profiles when an order is placed by filling the profile ids that you will find in:
    SALESORDers Export ToolExport Profiles

STEP 2: Configure your profiles

During that step, the different tabs that can be found in the configuration of a profile will be described. First, the profile configuration will be detailed followed by the different kinds of templates, the filters that can be created to adjust your configuration, the FTP configuration and the scheduled tasks in order to generate the profile.

You can edit or create a new profile from:
SalesOrders Export ToolExport Profiles

From there, you have the possibility to delete or generate several profiles at a time.

The Tool Box or so-called "Black Box"


When creating a profile, you should see a blackbox on the right of your screen. The Orders Export Tool extension includes that tool to help you create your profile and see what is wrong.

The blackbox is inevitably a very useful tool. This will help you to configure your data feed more quickly.

Here are the different options of the blackbox:

Check Syntax

This button allows you to check if your syntax is correct. It helps you to see if you have forgotten a bracket or a comma by underlining in yellow the part of text that contains a mistake.

Library

You might want to know which syntax to use? No worries, Orders Export Tool includes a full library of all data available for all instances: order, products, payment, invoice, shipment, creditmemo...

Check Data

When clicking on that button, you'll see a preview of your profile. It's very useful to see if the values are correctly retrieved or if your filters are working.

Configuration

When creating or editing an export profile in Orders Export Tool, you have to be aware of some basic settings.

File configuration

To configure your file, fill in the below fields:
  • File name
    The base name of the exported files (eg: myOrders), no need to add any file extension (xml, csv, txt), the extension does it for you.
  • Encoding type
    Choose the encoding type you want to use.
  • File type
    This is the main setting that defines if you want either an XML file type or a CSV/TXT file type. Depending on this setting the template section will be managed differently.
  • File name format
    Your file name can be completed with the current date at the time of the exportation. Different formats are available.
  • Create one file for each order
    Choose to export one order per file or not.
  • Add a counter as the 1st column
    Choose if you want the first column to be a counter.
  • Sort orders by
    Define how you want the orders to be sorted.
  • Sorting direction
    Choose the ascending or descending sorting.


Product filters

Choose the types of product you want to export.

Orders filters

This section allows you to define which group of orders must be exported.

  • Export from Store view
    Allows you to choose one or more store views from your webstore(s) to use in the exportation process.
  • Start with order #
    Allows you to specify an order number from which to start the export process.
  • Register the last exported #
    Allows you to automatically register the last exported order into the 'Start with order #' input.
  • Flag each exported order
    Allows you to flag each exported order as exported in:
    SalesOrder
  • Export only unmarked orders
    Allows you to specify that only the orders not yet flagged must be exported.
  • Update the order status
    Allows you to update the order status or not.

Template

In this tab, you'll be able to configure your profile template according to your needs. Orders Export Tool allows you to create different kinds of file:

  • XML profile
  • CSV / TXT profile

Note that you have the possibility to use some php code directly in your template.

XML file template

An XML template is made up of 3 parts:

  • Enclose xml tag content inside CDATA (recommended)
    Choose to enclose the content of your XML tags between CDATA or not.
  • Header pattern
    Is at the start of the file:
    <orders>
  • Order pattern
    Is iterated for each order included in the file:
    <order>
     <customer>
      {customer_lastname,[strtoupper]} {customer_firstname,[strtolower],[ucfirst]}
     </customer>
     <billing>
      {firstname billing} {lastname billing}
      {postcode billing} {street billing,[implode]}
      {city billing} {country_id billing}
     </billing>
     <shipping>
      {firstname shipping} {lastname shipping}
      {postcode shipping} {street shipping,[implode]}
      {city shipping} {country_id shipping}
     </shipping>
     <items>
     {product::start}
      <item id="{item_id product}">{name product}</item>
      <weight>{weight product}</weight>
     {product::end}
     </items>
    <order>
  • Footer pattern
    Is at the bottom of the file:
    </orders>

The XML structure allows you to use iterative syntax in different parts of the template, as follows:

{product::start}
 <item id="{item_id product}">
  <name>{name product}</name>
  <weight>{weight product}</weight>
 </item>
{product::end}

In most cases, orders contain more than one product, so it may be useful to create an iteration that loops for each ordered product. All the content between the opening and closing markers will be repeated for each product and all dynamics values will be replaced:

{product::start}
 ...
{product::end}

These iteration markers can be used for all order instances:

{payment::start}
 ...
{payment::end}
{invoice::start}
 ...
{invoice::end}
{shipment::start}
 ...
{shipment::end}
{creditmemo::start}
 ...
{creditmemo::end}

CSV / TXT file template

To create a CSV/TXT datafeed, you just have to choose 'csv' or 'txt' in File type, in the Configuration tab. The template tab will be updated to match with the file type.

  • Include header
    Allows you to include or not the column's name in the first row of your CSV/TXT file.
  • Columns name
    Is for the attribute name that can be displayed at the top of the file.
  • Pattern
    Works in the same way as in XML files.
    Like in XML files, you're allowed to use PHP code if you want to customize the pattern. You just have to write your PHP code in one single line, and it will work perfectly.
    You can add a field by using the button Add field . The fields can then be re-ordered easily by using the up and down arrows.
  • Field delimiter
    Lets you choose which kind of delimiter you want to use to separate your fields.
  • Fields enclosure
    Lets you choose which kind of enclosure you want for your data.

The main difference with the XML mode is that you can't use any iteration instructions. Instead, Orders Export Tool uses an auto-consolidation internal process. This simply means if you try to get the value of any attribute of an instance (product for example) that contains several items, the extension will automatically duplicate the txt/csv line for each item.

With the following configuration:

Logically the module should export one line for each order, but some orders may contain several product items. The extension will create several lines for the same order, as in the following output example:

Order#         Product Name          Product Sku
#10000001      my product A          AAA
#10000001      my product B          BBB
#10000001      my product C          CCC
#10000002      my product D          DDD
#10000003      my product B          BBB
#10000003      my product E          EEE
...

Filters

In the Filters tab, you can define the types of orders and customers you want to include in your export profile. You have also the possibility to create more advanced filters that will best meet your needs.

Order status

This section allows you to specify the type of order you want to export. At least one status must be selected.

Customer Group

In this tab, choose the customer group of the orders you want to export. At least one customer group must be selected

Advanced Filters

In that tab, you can create more precise filters. For example, you can choose to export only one specific order by setting a filter:

order > increment_id | = | Id of your order

You can also export orders placed by customers whose lastname ends with 'son':

order > customer_lastname | like | %son

You have the choice between several options:

  • =, >, <...
    Equal to, greater than, lower than, greater than or equal to, less than or equal to, different from.
  • LIKE / NOT LIKE
    like: starts / ends with the character string / includes the character string.
    Not like: doesn't start / end with the character string / doesn't include the character string.
  • IS NULL / IS NOT NULL
    is null: the value is null.
    is not null: the value is not null.
  • IN / NOT IN
    in: is in (selection of several options).
    not in: is not in (selection of several options).

Output settings

With Orders Export Tool, you have many possibiities to export your profiles.

Storage settings

The first solution is to store your file directly on your server.

FTP settings

You can also configure the ftp settings. For example:

  • Upload by FTP
    Select Yes if you want to upload your data feed using FTP.
  • Host
    In that field, fill in the host. For example:
    wyomind.com
  • Login
    It is your login to connect to server.
  • Password
    It is your password to connect to server.
  • Destination director
    is a relative path from the entry directory when you connect to the ftp.
    For example:
    /var/export/ftp
  • Use SFTP
    Select Yes if you are using SFTP.
  • Use Active mode
    If you are using SFTP, you don't have to care about the passive/active mode.

Email settings

Finally, you can choose to send your profiles by email. Don't forget to separate the email addresses with a comma.

The file is uploaded each time the feed is generated manually or automatically.

Scheduled tasks

In that tab, you can choose the days and hours when you want your profiles to be generated.

STEP 3: Export your orders

Now that your profiles are configured, you can export your orders into these files.

You will be able to see to which profile each order has been exported in:
SalesOrders

For each order, different notifications will be displayed in the Exported to column:

  • default (X)
    The order has been exported to the profile named default (only when the Mark each exported order option of the profile configuration is on YES).
  • No profile defined
    There is no profile defined for the product(s) of the order.
  • => default
    The profile defined for that order is default.

There are several ways of exporting your orders to any one of your profiles.

Generate the profile

By generating a profile, the orders that match with the profile configuration are automatically exported to that file.

Choose a profile and simply select the Generate option from the Action dropdown in
SalesOrders Export ToolExport profiles

A message is displayed and indicates how many orders have been exported to the file.

Manually export the orders

Choose an order and click on View  in:
SalesOrders

There you can select a profile for each product of the order. For example: default

You can configure the profiles in SalesOrders Export ToolExport profiles.

Go back in:
SalesOrders

In the Exported to column, the order displays:
=> default

This means that the order will be generated to that profile.

Now go back to the order View and click on Export . The order will then be exported to the profile(s) you've defined only if the order is matching with the configuration of the profile.

Export only unmarked orders

2 options are interesting in the Configuration tab of your profile from:
SalesOrders Export ToolExport profiles

  • Mark each exported order
    in:SalesOrders
  • Export only unmarked orders

If you don't want to export several times the same orders, you can define both options on YES. Then only the unmarked orders will be exported.

If at any time, you want to export a new time an order that has already been exported, you have the possibility to unmark that order by clicking on the cross next to the profile name in:
SalesOrders

Then, when the profile will be run, the order will be exported a new time.

STEP 4: Create your custom attributes

In some cases you might need to get the value of one attribute that is not available in any of the default instances (order, product, address, payment, invoice, shipment or creditmemo) or you might need to use the value of one attribute but with a computed output.

Orders Export Tool allows to create your own customized attributes directly from your admin panel by using some php code.

Directions

In order to create a valid customized attribute, you must respect these rules:

  • $value is used to store the data that must be returned. You can also use the return instruction.
  • $item refers to the item of the current instance , eg :
    {your_custom_attribute order} = $item refers to the order instance
    {your_custom_attribute product} = $item refers to the current product instance
    ...
  • $data is an associative array that contains all the instances data of the current order.
    $data["products"] = contains all the product data relative to the current order
    $data["payments"] = contains all the payment data relative to the current order

Examples

Below are 3 examples of common customized attributes:

  • Get the color for each product of the order
<?
 $product=Mage::getModel('catalog/product');
 $product->load($item->getProductId());
 $value=$product->getColor();
 return $value;
?>

or

<? return Mage::getModel('catalog/product')->load($item->getProductId())->getAttributeText('color'); ?>

  • Get a consolidated string of all product skus in the order
<? $skus = array();
 foreach ($data['products'] as $product) {
 $skus[]= $product->getSku();
 } return implode(',',$skus);
?>

  • Get the status of an order and retrieve a computed value
<? switch($item->getStatus()){
 case 'canceled': $value= 'MerchantCanceled'; break;
 default : $value= 'BuyerCanceled';
 } return $value;
?>
